Description
Kit cadre
Cadre:
Teammachine 01 AMP | 01 Premium Carbon with Aerocore Design | Integrated Battery | ICS Technology Stealth Cable Routing | Stealth Dropout Design | TCC Race Compliance Level | Flat Mount Disc | 12 x 142mm Thru-Axle
Fourche:
Teammachine 01 AMP | 01 Premium Carbon | ICS Technology Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle | 48mm offset Size 47-51 | 43mm offset Size 54-61
E-System
Unité Moteur:
TQ-HPR40 Drive Unit
Batterie:
TQ Battery | 290 Wh | Certified by UL LLC
Écran:
TQ Graphic color Display | 2″ O-LED | Bluetooth / ANT+
Commande d’Assistance:
Mode change with Shimano STI hood buttons
Chargeur:
TQ 4A Charger
Cockpit
Cintre:
ICS Carbon Evo | One Piece Full Carbon Cockpit | 127mm drop, 70mm reach, 8° flare
Grips / Guidoline:
BMC Tacky 3mm
Seat
Tige de Selle:
Teammachine SLR 01 Gen 5 | 01 Premium Carbon Aero Shaped Seatpost | 0mm Offset Size 47-51 and 10mm Offset Size 54-61
Selle:
Fizik Vento Argo R5 | 140mm
Transmission
Pédalier:
Praxis Type-5 eCrank Carbon Road | LT2 chainrings | 46mm chainline
Plateaux:
50-34T
Capteur de puissance :
TQ drive unit power meter
Cassette:
SHIMANO Ultegra (CS-R8101)
Taille de cassette:
11-34T
Chaîne:
SHIMANO CN-M8100
Dérailleur Avant:
SHIMANO Ultegra Di2 (FD-R8150)
Dérailleur Arrière:
SHIMANO Ultegra Di2 (RD-R8150)
Leviers de Vitesses:
SHIMANO Ultegra Di2 (ST-R8170)
Vitesses:
2 x 12
Freins
Leviers de Frein / Étriers:
SHIMANO Ultegra (BR-R8170)
Disques:
SHIMANO Ultegra (RT-CL800)
Largeur de Pedalier:
160 / 160mm
Roues
Jantes:
CR 40 Carbon | Tubeless Ready | 40mm
Moyeux:
TXC-812 & TXC-240A Center Lock
Pneus:
Pirelli P Zero Race TLR RS | Tubeless | 28mm
Information Tubeless:
Tubeless Rim | Tubeless Tires
Accessoires
Contenu inclu dans la boite:
Integrated Bottle Cages | Integrated Rear Light 20 StVZO | Computer mount for Garmin, Wahoo and GoPro mount
Informations supplémentaires
Espace pour les pneus:
32mm measured tire
Poids sans Pédales:
10.2kg | Size 54 as pictured with all accessories
